ESP32-D0WD-V3 - Wi-Fi & Bluetooth Combo Chip

$1.43

Leave a review

SKU: GC-ESP32-D0WD-V3

MPN: ESP32-D0WD-V3

Manufacturer: Espressif Systems

Delivery: Ships within 7-14 business days
Shipping is Free on orders over $75

We've Got You Covered

delivery truck

1 year comprehensive warranty support for all products

hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

Authorized North America Distributor Stamp

The ESP32-D0WD-V3 is a 2.4 GHz Wi-Fi and Bluetooth combo chip based on the ECO V3 wafer and fits in a 5x5mm footprint.

It's designed with the TSMC ultra-low-power 40 nm technology. It is designed to achieve the best power and RF performance, showing robustness, versatility and reliability in a wide variety of applications and power scenarios.

Features

  • SMD IC
  • ESP32 ECO V3 wafer
  • Dual-Core MCU
  • Wi-Fi 2.4 GHz
  • Bluetooth v4.2 BR/EDR and BLE
  • QFN 48-pin
  • 5x5 mm chip package
  • 520 KB SRAM, 448 KB ROM, and 16 KB RTC SRAM

Documents and Drivers

Documentation

ESP32 Series Datasheet

ESP32 Technical Reference Manual

ESP32 ECO V3 User Guide

ESP32-DOWD-V3 BQB Certification

Specifications

Chip Package

QFN 5x5

Controller(s)

  • Infrared Remote
  • DMA
  • Bluetooth Link
  • BT 4.2
  • SD/SDIO/MMC HOst
  • PID
  • Efuse
  • Media Access Controller (MAC)
  • Pulse Width Modulation (PWM)
  • TWAI

Core

Duel Core

CPU

Xtensa® 32-bit LX6 microprocessors

Frequency

240 MHz

Interface(s)

  • 34 × programmable GPIOs
  • 12-bit SAR ADC up to 18 channels
  • 2 × 8-bit DAC
  • 10 × touch sensors
  • 4 × SPI, 2 × I²S, 2 × I²C, 3 × UART
  • 1 host (SD/eMMC/SDIO)
  • 1 slave (SDIO/SPI)
  • Ethernet MAC interface with dedicated DMA and IEEE 1588 support
  • Two-Wire Automotive Interface (TWAI®, compatible with ISO11898-1)
  • IR (TX/RX)
  • Motor PWM
  • LED PWM up to 16 channels
  • Hall sensor

Memory

  • 520 KB SRAM
  • 448 KB ROM
  • 16 KB RTC SRAM

MPN

ESP32-D0WD-V3

Pins

48 Pin QFN package

Power Supply

2.3 V to 3.6 V

Temperature Range

  • Operating: -40ºC to 125ºC (-40ºF to 257ºF)
  • Storage: -40ºC to 150ºC (-40ºF to 302ºF)

Timers

4 General-Purpose Timers

Watchdog Timer

3
