This product is discontinued and no longer available.
RAK7249 - LoRaWAN Outdoor Gateway
RAK7249 - LoRaWAN Outdoor Gateway
Product Images
RAK7249 - LoRaWAN Outdoor Gateway
SKU: GC-RAK7249-US915
MPN: 716052
Manufacturer: RAKwireless Technology Co., Ltd.
We've Got You Covered
1 year comprehensive warranty support for all products
30 day money back guarantee
*some exceptions apply
Product Information
Product Description
The RAK7249 is a reliable and easy to use gateway with LoRaWAN® software. It is ideal for commercial and industrial Internet of Things (IoT) with an IP67/NEMA-6 grade enclosure for outdoor use.
It includes Wi-Fi, LTE, and Ethernet capabilities and a built-in GPS module. The device can support up to 8 LoRa channels and can transmit up to 15 kilometers in open area.
The Gateway is designed for quick deployment with out-of-the box firmware as well as the ability for customized solutions. It offers an openWRT platform and an open SDK for flexibility in different situations.
The RAK7249 Gateway Includes:
Qty |
Kit Item |
|---|---|
| 1 |
LoRa® Antennas |
| 2 |
LTE Antenna |
| 1 | GPS Antenna |
| 1 | 2.4G Wi-Fi Antenna |
| 1 | IP67/NEMA-6 Enclosure |
Features
- Dual LoRa® Concentrators for up to 16 channels
- PoE + Surge Protection
- IP67/NEMA-6 industrial-grade enclosure with cable glands
- Built-in GPS module
- Built-in LoRa® Server
- OpenVPN
- Software and UI sit on top of OpenWRT
- LoRaWAN® 1.0.2
- LoRa® Frame filtering (node whitelisting)
- MQTT v3.1 Bridging with TLS encryption
Documents and Drivers
Documentation
RAK7249 Gateway Datasheet
Specifications
Antenna
- 2x LoRa® Antennas
- 1x LTE Antenna
- 1x GPS Antenna
- 1x 2.4G WiFi Antenna
Channels
16
Dimensions
220mm x 220mm x 104mm
Enclosure
IP67/NEMA-6 industrial-grade with cable glands
Included in Box
- 2x LoRa® Antennas
- 1x LTE Antenna
- 1x GPS Antenna
- 1x 2.4G WiFi Antenna
- 1x Power Board
- 1x Backup Battery
- 1x IP67 Enclosure
MPN
RAK7249-US915
Power
PoE and Surge Protection
Product Weight
5.05kg including the mounting kit
Security/Protection
TLS encryption
Software
- LoRaWAN® 1.0.2
- OpenVPN
Temperature Range
-30°C to 55°C (-22°F to 131°F)
