NET232-DTE (male)
Serial to Ethernet
Intelligent Cable Adapter $99

The NET232 is an intelligent plug-and-play RS232-to-Ethernet cable adaptor that enables any device or machine with a serial port, to become Ethernet network and Internet enabled.   Go from TCP/IP to serial with the NET232, an intelligent RJ45 to DB9 adapter.   It features a powerful built-in device server, so you can access your serial device from anywhere in the world over internet!  The NET232 is easily configured via a web page, and can also be set up through the serial port. You can use DHCP, AutoIP or assign a Static IP address to the NET232!

There are two basic modes of operation, "Redirector" and "Serial Tunneling".

Redirector Mode:  In Redirector Mode, only one NET232 is needed per serial device.  ComPort Redirector Software (free with purchase) is installed on your Windows PC to create a "virtual" COM Port (e.g. COM3).  You can then use this COM port in your Software application just as you would any physical COM port attached to your PC.  Create a virtual COM Port for every NET232 device on your network and connect to them all from a single PC!

Serial Tunneling Mode:  In Serial Tunneling mode, two NET232's are used to create a "Serial Tunnel" over Ethernet.  This can be thought of as cable replacement.  Each NET232 is configured to have a remote IP address that is the other NET232 in the pair.  No software is required to be loaded on a PC.  This is also an excellent option for non-windows PCs or computers.  Now you have an infinite length RS232 cable that is connected over the internet.

NET232 FEATURES:

Serial Interface
Data Rates	300 bps to 921,600 bps
Characters	7 or 8 data bits
Parity	odd, even, none
Stop Bits	1 or 2
Flow Control	XON/XOFF, RTS/CTS
Connector	DB9 - DTE (male).   Null Modem adapter included.   DCE (female) and custom cables/connectors (call) also available
Network Interface
Interface	Ethernet 10Base-T or 100Base-TX (Auto-Sensing)
Connector	RJ45
Protocols	TCP/IP, UDP/IP, ARP, ICMP, SNMP, TFTP, Telnet, DHCP, BOOTP, HTTP, and AutoIP
Indicators (LED)
10Base-T connection 100Base-TX connection Link & activity indicator - Full/half duplex Power
Management
SNMP, Telnet, serial, internal web server, and Microsoft Windows®-based utility for configuration
Security
Password protection Optional 256-bit AES Rijndael encryption
Internal Web Server
Storage Capacity	384KB for web pages
Architecture
CPU	Based on the DSTni-EX enhanced 16-bit, 48MHz or 88MHz, x86 architecture
Memory	256KB SRAM and 512KB flash
Firmware	Upgradeable via TFTP and serially
Power
Input Voltage	8-24 VDC
Packaging
Dimensions	63.5 x 42.67 x 20.17mm (2.5 x 1.58 x .794 in) - Case without Cable
Weight	92 g (3.2 oz) - Approximate, Without Power Supply
Included Software
MS Windows®-based DeviceInstaller software device installer and MS Windows-based Comm Port Redirector
Certifications
CE

NET232 Data SheetNET232 User ManualRedirector User Guide

NET232/Serial RS232 Product FAQ
