5V USB-A Wall Mount Power Adapter, 5W
5V USB-A Wall Mount Power Adapter, 5W
Product Images
5V USB-A Wall Mount Power Adapter, 5W
$10.00
SKU: GC-PS-5VDC-1A-US-USBA
MPN: GC-PS-5VDC-1A-US-USBA
Manufacturer: Grid Connect Inc.
Stock Status: Out of stock (more on the way)
We Have You Covered
Product Information
Product Description
This 5W wall mount AC/DC power adapter delivers a regulated 5V at up to 1000 mA through a USB Type-A output. Its fixed US blade plug accepts universal input voltage from 90 to 264 VAC, making it compatible with standard North American outlets. Built to Energy Efficiency Level VI standards, it draws less than 0.1W at no load and runs at 77% efficiency — well within DoE and EU Ecodesign requirements. Class II double-insulated construction with 3000 VAC input-to-output isolation keeps it compliant for a wide range of end-product applications.
Documents and Drivers
Documentation
Data Sheet
Specifications
Output
5.0 V DC / 1000 mA, USB Type-A connector
Input
90–264 VAC, 47–63 Hz, fixed US blade
Efficiency
77%; Energy Efficiency Level VI compliant
No-load power consumption
<0.1 W
Input-to-output isolation
3000 VAC
Total output regulation
±5%
Short circuit protection
hiccup mode with auto recovery
Operating temperature
0°C to +60°C (32°F to 140°F)
Safety approvals
UL/cUL, CB, TUV, CE, UKCA, CCC, AU/NZ
EMC
EN55032 Level B; FCC Part 15 Subpart B
Dimensions
2.17 x 0.95 x 1.40 in (55.1 x 24.1 x 35.49 mm
Weight
0.28 lb (80 g)
