NEW
$449.95
DB25-to-4x-DB9: 4 x CAN Cable Adapter
DB25 to 4xDB9 CAN bus cable adapter used for CANmod.router
DB25-to-4x-DB9: 4 x CAN Cable Adapter
Product Images
DB25-to-4x-DB9: 4 x CAN Cable Adapter
$79.95
SKU: GC-CSS-DB25-4X-DB9-CABLE
MPN: #219 DB25-to4x-DB9
Manufacturer: CSS Electronics ApS
Delivery: Ships within 4-6 business days
Free shipping to the US on orders over $100
We Have You Covered
1 year comprehensive warranty support for all products
30 day money back guarantee
*some exceptions apply
Product Information
Product Description
The DB25-to-4x-DB9 adapter cable lets you directly connect 4 CAN buses to your CANmod.router. This capability allows you to receive and transmit CAN traffic.
Adapter Pinout
| DB25 (female) | Function | DB9 CAN-S1 | DB9 CAN-S2 | DB9 CAN-S3 | DB9 CAN-S4 |
|---|---|---|---|---|---|
| 1 | CAN-S4 H | 7 | |||
| 2 | CAN-S4 L | 2 | |||
| 14 | CAN-S4 GND | 3 | |||
| 18 | CAN-S3 H | 7 | |||
| 17 | CAN-S3 L | 2 | |||
| 5 | CAN-S3 GND | 3 | |||
| 22 | CAN-S2 H | 7 | |||
| 21 | CAN-S2 L | 2 | |||
| 9 | CAN-S2 GND | 3 | |||
| 12 | CAN-S1 H | 7 | |||
| 13 | CAN-S1 L | 2 | |||
| 25 | CAN-S1 GND | 3 |
Specifications
Cable Length
20 cm ( .7 in )
Connectors
DB25 (female), 4 x DB9 (male)
Temperature
-20°C ~ 80°C (-4°F ~ 176°F)
Weight
210 g ( .46 lb )
