L-DCIM - LoRa WIRELESS SENSOR GATEWAY

$695.00

Leave a review

SKU: GC-AK-L-DCIM-US

MPN: L-DCIM-US

Manufacturer: Discontinued

Stock Status: Out of Stock

Delivery: Not available
Qualifies for Free shipping

THIS PRODUCT IS NO LONGER AVAILABLE.


Phone: (800) 975-4743 or (630) 245-1445
Email: sales@gridconnect.com

We've Got You Covered

delivery truck

1 year comprehensive warranty support for all products

hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

Authorized North America Distributor Stamp

Data Center Infrastructure Monitoring/Management with LoRa™





The L-DCIM is a wireless gateway designed for Internet of Things (IoT) uses and allows for easy monitoring and management of sensors. The gateway is supported with AKCPro Server monitoring software and LoRa radio technology for long range bi-directional communication. The gateway supports up to 100 wireless LoRa sensors or a total of 1,000 data points and includes Wi-Fi, Ethernet, and two USB inputs.



LoRa™ Radio

With the LoRa technology the device is able to maximize distance and signal penetration in low-signal areas such as basements and elevator shafts. It offers real-time broadcast of sensor status as well as graph data as frequent as every 10 seconds. Other advantages of LoRa radio technology includes:

L-DCIM sensor diagram
  • Increased battery life
  • Frequent broadcasting
  • “Listen before talk” to minimize packet collisions
  • Utilizes the shortest spreading factor
  • Individually tuned external antennas
  • Save on cabling and installation costs
  • Fewer base units and IP addresses



AKCPro Server Monitory Platform

The AKCPro server platform is a world-class software that supports monitoring of all network enabled devices such as intelligent PDU’s, UPS’s, or CRAC units. The platform offers customized desktop interface as well as wireless access with a dedicated tablet view. This allows a technician to remotely monitor sensors in real-time while walking the center.

L-DCIM Tablet View L-DCIM Tablet View

The AKCPro server includes:

  • Drill Down Mapping
  • Drawing Program to Create Floorplans
  • Graphing
  • Custom Dashboards
  • Tablet User Interface
  • Synchronization of Sensors with video



Common Applications Include:

  • Data Centers
  • Pharmaceuticals
  • Hospitals
  • Warehousing
  • Cold Storage
  • Distribution Centers

Features

Features of the L-DCIM


  • Two (2) USB inputs
  • Wi-Fi & Ethernet connection


LoRa™ Radio

  • Increased signal penetration
  • Maximized signal distance
  • Fewer base units and IP addresses
  • Save on cabling and installation costs
  • Increased battery life
  • “Listen before talk” to minimize packet collisions
  • Frequent broadcasting
  • Utilizes the shortest spreading factor
  • Individually tuned external antennas


AKCPro Server Monitory Platform

  • Custom Dashboards
  • Tablet User Interface
  • Graphing
  • Drill Down Mapping
  • Drawing Program to Create Floorplans
  • Synchronization of Sensors with video

Documents and Drivers

Documentation

L-DCIM Product Information View (PDF)

Specifications

ANTENNA

Wi-Fi and Di-Pole LoRa

CERTIFICATIONS

FCC Part 15C, CE EN300220-2

CONNECTORS

10/100 Ethernet Port
Two (2) USB 2.0 Ports

DIMENSIONS

DCIM Unit: 52.14 x 112.64 x 94.95 mm
Wi-Fi Antenna: 112.55 mm
Di-Pole Antenna: 139 mm

INDICATORS LED

Power and Network Connectivity

MEMORY

8GB Embedded Memory

MOUNTING

DIN Rail, Wall Mount, Desktop

MPN

L-DCIM-US

PRODUCT POWER SUPPLY

External 5V 3A Power Adapter

RADIO

LoRa™ Radio
902-915 MHz (US)
Max TX Power +20dBm

TEMPERATURE RANGE

Operating Temp: -15ºC to 50ºC (5ºF to 122ºF)
Humidity: 20% to 80% (non-condensing)

VOLTAGE

100V ~ 240V - 0.22A
