$225.00
This product is discontinued and no longer available.
Suggested replacement: SP2+ Basic Version - sensorProbe2+
sensorProbe2+ Environmental Monitoring Solution
sensorProbe2+ Environmental Monitoring Solution
Product Images
sensorProbe2+ Environmental Monitoring Solution: 2 ports
SKU: GC-AK-SP2-PLUS-2PT
MPN: SP2+B
Manufacturer: AKCP Co Ltd.
We Have You Covered
Product Information
Product Description
The SP2+ comes with 4x intelligent sensor ports which connects to the entire wide range of environmental and security based AKCP sensors. The controller comes in 2 versions, both with SNMPV3 support.
2-Port Option
Ideal option when only 1 or 2 sensors are needed for your current application, and you don’t know if more will be needed in the future. The SP2+ comes with 2 ports enabled for connecting to any 1 or 2 AKCP sensors. The other 2 ports are locked which makes future expansion to 4 ports possible. When the time comes to expand your device a simple download software purchase, SP2+ license, can be used to enable the other 2 ports.
4 Port Option
This option is ideal if you currently need 3 to 4 ports or know you will need them in the future. This option comes with all 4 ports enabled so 1 to 4 AKCP sensors can be used immediately.
Additional Features Available :
- security features such as support for IPV6 and Radius
- internal 4G cellular data modem with an optional GPS antenna
- RS485 option, SP2+E, for monitoring Modbus devices such as a generator, or other industrial equipment
If interested in the additional features, please contact us for more information.
Order Summary
SKU |
# of Ports
|
Manufacturer Part # (MPN) |
---|---|---|
GC-AK-SP2-PLUS-2PT | 2 Port | SP2+ (DISCONTINUED) |
GC-AK-SP2-PLUS-4PT | 4 Port | SP2+ and 4PUN (DISCONTINUED) |
Features
- IP based, including SNMPv3, HTTPS, VPN
- Send encrypted SNMP Trap and Email Notifications
- Supports 4 Intelligent Sensors or up to 20 Dry Contacts
- Optional cellular modem with external antenna
- Optional Expansion Module connectivity
- Virtual Sensors
- Optional Modbus
- Optional Power over Ethernet (PoE)
Documents and Drivers
Documentation
SP2+ Datasheet
Specifications
Connector(s)
- 4 RJ-45 Sensor Ports for connecting AKCP Autosense Sensors
- Up to 20 Dry Contact Input and Output (0VDC/5VDC)
- Input Optional RJ-45 Expansion / Modbus RS485 Port
Current
0.22A
Dimensions
4.5" x 2.5" x 1.25"
Humidity
Min. 20% – Max. 80% (Non-Condensing)
Indicators LED
- Power
- Network connectivity
- Sensor online and threshold status
Input/Output
- 4x RJ-45 Sensor Ports (SP2+)
- 2x RJ-45 Sensor Ports with 2x additional locked under software (SP2-V2)
- 1x 10/100 Ethernet Port
- Optional 3/4G integrated cellular modem with external antenna (Optional GPS feature)
- 1 sensor port can be used as expansion port or Modbus RS485 on SP2+E version (supports up to 4 CCU, E-Sensor8 or E-Opto16) *
- Includes 5 free virtual sensors
- Configurable output signals (0VDC/5VDC) on any of the 4 RJ-45 sensor ports
Interface(s)
- Standard 10/100 Mbps Full Duplex
- Ethernet RJ-45 Port
Mounting
- 0U rack-mountable
- Compatible with AKCP’s DIN Rail Clips
MPN
SP2+, 4PUN
Power
- External 5.5V 3A Power Adapter
- Input Voltage and Current ratings : 100V~240V - 0.22A
- Optional PoE IEEE 802.3af support
Product Weight
0.3 kg
Protocols
- Rsyslog
- MQTT / MQTTS
- SNMP V1/2/3
- IPV6
- RADIUS
- TACACS HTTPS
- Encrypted E-mail
Temperature Range
-35ºC to 80ºC (-31ºF to 176ºF)
