VPC3+C PROFIBUS Slave Controller - SPC3 Pin Compatible

SKU: GC-VPC3-CLF

MPN: PALF2030, PALF2080

Delivery: Ships same or next business day

Availability: in stock

30 day Money Back Guarantee *Some Exceptions Apply

Warranty: 1 year Comprehensive support for all products

Authorized North America Distributor Stamp



The VPC3+CLF product is at EOL with last time buy 4Q18: Product Change Notice.

--------------------------------------------------------------

VPC3+C is a communication chip with 8 Bit Microprocessor interface for intelligent PROFIBUS slave applications. The VPC3+C is Pin, function and software compatible with Siemens SPC3, 6ES7-195-0BD04-0XA0.

The VPC3+C handles the message and address identification, the data security sequences and the protocol processing for PROFIBUS-DP. In addition the acyclic communication and alarm messages, described in DPV1 extension, are supported. Furthermore the slave-to-slave communication Data exchange Broadcast (DXB) and the Isochronous Mode (IsoM), described in DPV2 extension, are also provided.

Automatic recognition and support of data transmission rates up to 12 Mbit/s, the integration of the complete PROFIBUS-DP protocol, 4 Kbytes communication RAM and the configurable processor interface are features to create high-performance PROFIBUS slave applications. The device can be operated with either 3.3V or 5V single supply voltage. For 3.3V operation the inputs are 5V tolerant.

There are two versions available, the VPC3+CLF (PALF2030, formerly PALF2003), and the VPC3+CLF3 (PALF2080 Formerly PALF2008). The VPC3+CLF3 adds DP-V2 clock synchronization, and uses 20% less current than the VPC3+CLF.

Certifications Package PQFP 44 (RoHS compliant)
Inputs 5V tolerant inputs
Memory 4kB communication RAM
Mpn PALF2030, PALF2080
Protocols Supporting PROFIBUS DP-VO, DP-V1 & DP-V2 protocol
Software Pin, function and software compatible with SPC3 from Siemens
With canadapter 366

English Documents


VPC3+C Data Sheet (PDF)

VPC3+C User Manual (PDF)

VPC3+C Software Manual (PDF)


Spanish Documents


VPC3+C Data Sheet (PDF)

VPC3+C User Manual (PDF)


Downloads


VPC3+C Software (ZIP)
