This product is discontinued and no longer available.

Wireless Adapter for Switch Type Sensors

Leave a review

SKU: GC-AK-WTS-SW

MPN: WTS-SW-US

Manufacturer: AKCP Co Ltd.

We Have You Covered

Price Match delivery truck hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

Authorized North America Distributor Stamp

This battery powered LoRa™ radio module enables you to plugin AKCP switch type sensors for monitoring over the Wireless Tunnel™ network. These sensor types should ideally be externally powered, as battery life will be shortened on these sensor types. The WTS-SW can be used with the any of the AKCP switch output type sensors.

Compatible Sensors
  • Rope Water Sensor
  • Vibration Sensor
  • Motion Detection
  • Smoke Detector
  • AC Voltage Detector
  • Security Sensor

    • We do not recommend to use Smoke Detector, Water Detector/Rope Detector or Motion Detector without USB power in order to keep battery life.

    Features

    • 4x AA Batteries for backup
    • 5VDC or 12VDC powered
    • LED indicators for power, status and RSSI
    • Optional DIN rail or pipe mounting

    Documents and Drivers

    Documentation

    Wireless Adapter for Switch Type Sensors Datasheet

    Specifications

    Certifications

    FCC Part15C, CE EN300220-2

    Dimensions

    76 x 77 x 120mm

    Humidity

    Min. 20% – Max. 80% (Non-Condensing)

    Indicators LED

    • Mode
    • Status
    • RSSI

    Interface(s)

    Cat5 cable with female RJ45 connector, default 1ft long

    Mounting

    Wall hanging, DIN rail, Pipe Clamp

    MPN

    WTS-SW

    Number of Sensors

    5 (3 + 2)

    Power Consumption

    Average 12m Watt, 10uA in Idle, without sensor connected

    Power Source

    • Via micro-USB port
    • 4x AA batteries for backup power

    Radio

    LoRa (R) Radio Regional plans: US915: 903~915Mhz, Max TX Power +17dBm

    Sensor(s)

    • Sensor Status
    • Edge counter

    Temperature Range

    -35°C to 80°C (-31°F to +176°F)

    Type of Sensors

    Sensors Supported:

    • Smoke Detector
    • Security Sensor
    • Vibration Detection Sensor
    • Water Detector or Rope Water Detector
    • Motion Detector
    • AC voltage Detector
