Another thing that can be done with ProfiTrace is to look at the messages that are being sent on the bus. To access these messages, click on the “Messages” tab that is above the matrix. This will be in line with the live list and statistic tabs that we have previously used.
When looking at the live list on the main screen, the user is able to see real time updates of what is going on. If the user had just walked up to the instillation and saw that all of the devices are green, they would assume that there is nothing wrong with the instillation. In reality, they would be seeing a real time representation of what is going on right now.
The next important thing to cover is the fact that there is a place where the GSD files are saved. In the “Settings” menu at the top of the screen, go to “Preferences.” At the bottom of the “General” tab in preferences, there is a section labeled “GSD directory locations.”
For now, stay on the main ProfiTrace page that is included in every kit that Grid Connect sells. To begin, click on the button that says “Init ProfiCore Ultra.” It will begin to initialize the ProfiCore Ultra, essentially it is checking the firmware that is loaded in the Ultra to make sure it is the latest firmware. Then it will begin to check the baudrate of the instillation. Once this is complete, there will be five boxes within the main matrix (grid) on the screen.
At this point, the ProfiCore Ultra should be connected to the training kit and the ProfiTrace 2 software is ready to launch. On the computer being used, go to “Programs,” then select “ProfiTrace V2.7,” which is the latest version.
The ProfiSwitch X5 is a multiple baud rate, multi-channel PROFIBUS Repeater with 5 channels. This device is a powerful package that ensures reduced installation complexity, increased time utilization, and better deployment of project resources. Having 5 channels of communication on 1 unit requires less repeaters and connectors to purchase. Quick connection of channels, auto baud rate detection, and unit termination reduces installation time and costs.
Industrial Ethernet fieldbus issues of the past are coming to life again in a new form. Large protocol interest groups and manufacturers of industrial equipment have a new platform to compete for revenue and to keep brand loyalty. Ethernet-based protocols are changing with time, many companies have similar protocol implementations as they essentially have been creating the same standard Ethernet connectors.
Grid Connect is committed to PROFINET and we provide an expanding selection of PROFINET products and services. Our engineering staff have deep expertise and knowledge in all things PROFINET and are able to help deliver leading edge solutions.
The first major announcement was that the PTO is changing its name to PROFIBUS & PROFINET International North America (PI). They also announced a new website for PROFINET information and application examples. You can visit the new site today at allthingsprofinet.com.
