ATC-863 Wireless 232, 485, or TTL Adapter: TTL Level

$87.74

SKU: GC-ATC-863-S0

MPN: ATC-863-S0

Manufacturer: ATC

Delivery: Ships within 2-3 weeks
Free shipping to the continental US on orders over $100

Serial Interface

We Have You Covered

Price Match delivery truck hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

The ATC-863 is a short distance (300m/980ft) wireless adapter for RS232, RS485, or TTL level signals. The ATC-863 provides 8 channels and baud rates up to 19.2K. The ATC-863 uses low power (max. 100mW) in the 429-433.30MHz frequency range.

Two ATC-863 are required for a communication connection. Select RS232, RS485, or TTL from the options menu as units only allow for one type of serial connection.

The RS485 version requires a RS485 configuration cable, not included.

Order Summary



SKU

Serial Interface

Manufacturer Part # (MPN)
GC-ATC-863-S0 TTL Level ATC-863-S0
GC-ATC-863-S1 RS232 ATC-863-S1
GC-ATC-863-S2 RS485 ATC-863-S2

Documents and Drivers

Documentation

ATC-863 User's Manual

Downloads

ATC-863 Product CD

ATC 863/871/873 RF module software for setup

Specifications

Baud Rate

up to 19.2 K

Channels

8

Current

  • Transmitting: <30mA
  • Receiving: <10mA

Dimensions

44 x 27 x 8 mm

Enclosure

Industrial Metal Enclosure

Frequency Band

ISM FSK/GFSK freq band, 433MHz

Humidity

5% to 95%

Interface(s)

  • RS232/RS485/TTL: -S1, -S2, -S0
  • RS422/485 side is 4 position terminal block

MPN

ATC-863

Power Supply

9VDC 200 mA External power supply included

Range

up to 300 m

Receiver Sensitivity

-110 dbm

Serial Types

372,371,376

Temperature Range

-35°C to +70°C (-31°F to +158°F)
