CANedge1 with GNSS/IMU: 8 GB SD Card

$519.95

Leave a review

SKU: GC-CSS-CANEDGE1-8GB-GNSS/IMU

MPN: #182 CANedge1 8GB + GNSS/IMU

Manufacturer: CSS Electronics ApS

Stock Status: In stock

Delivery: Ships same or next business day
Qualifies for Free shipping to the US

SD Card

We Have You Covered

Price Match delivery truck

1 year comprehensive warranty support for all products

hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

The 2x CAN/LIN logger records timestamped CAN data (CAN/CAN FD) to the extractable 8 GB industrial SD card.

It's easy-to-use: Simply connect the device to your CAN bus to start logging raw CAN data. Next, extract the data and process it using 100% free open source software/API tools - includes. file format conversion, DBC decoding and plot visualization.

The device includes GNSS/IMU, adding data such as position, speed, altitude, acceleration and more.

Ideal for recording CAN/LIN data over weeks, months or years - e.g. for diagnostics, OEM development or legal/warranty purposes.



Order Summary



SKU

SD Card

Manufacturer Part # (MPN)
GC-CSS-CANEDGE1-8GB-GNSS/IMU 8 GB SD Card
 #182 CANedge1 8GB + GNSS/IMU
GC-CSS-CANEDGE1-32GB-GNSS/IMU 32 GB SD Card #184 CANedge1 32GB + GNSS/IMU

Features


  • PLUG & PLAY: Log data out-the-box. Standalone - no PC required. Power via CAN connector
  • PRO SPECS: Extractable 8-32 GB SD. 2xCAN/LIN. CAN FD. Zero data loss. 50 µs RTC. Error frames. MF4
  • COMPACT: Only 8 x 5 x 2 CM. 100G. Aluminium enclosure. 4 LEDs. Configurable 5V power out (CH2)
  • CONFIGURABLE: Advanced filters. Transmit lists. Triggers. Cyclic logging. Silent mode. Encryption
  • GNSS + 3D IMU: Built-in GNSS/IMU. 3X accuracy via sensor fusion. Position, speed, acceleration & more
  • INTEROPERABLE: Free & open source software/API. MF4 to ASC/CSV. DBC support. Python. Dashboards

Documents and Drivers

Documentation

CANedge1 with GNSS/IMU Product Manual

CANedge1 with GNSS/IMU Datasheet

Specifications

Accuracy

  • Position: 2.0 m CEP (Circular Error Probable)
  • Heading: 0.3 deg | Pitch: 0.4 deg | Roll: 0.6 deg (68% at 30 m/s)
  • Velocity: 0.08 m/s

Certifications

CE, FCC, IC, KC and RoHS

Channels

  • 2 x CAN channels (incl. CAN FD support)
  • 2 x LIN channels

Connector(s)

2 x Standard D-sub 9 (DB9) connectors

Dimensions

Compact aluminum enclosure: 75 x 47 x 20 mm (2.95 x 1.85 x .79 in)

Indicators LED

Logger status via 4 external LEDs: Power, CH1, CH2, Memory

Input

Supply: +7V to +32V DC via the Channel 1 DB9 (e.g. via CAN connector power pin)

Module

Professional-grade u-blox NEO-M9V sensor module (92-channel) with built-in gyroscope and accelerometer

Power Consumption

Extremely low (~1 W) - no risk of battery drainage

Protocols

Log raw data from CAN based protocols (J1939/FMS, CANopen, NMEA 2000, OBD2, CAN FD, UDS, ...)

Real Time Clock

CAN frames are date & timestamped with 50 microsecond resolution (battery backup)

Standards

  • ISO 11898: Compliant with CAN (up to 1 Mbit/s) and ISO & Bosch CAN FD (up to 4 Mbit/s payload rate)
  • Compliant with LIN 2.0 up to 20 Kbit/s (support for Classic & Enhanced checksum format)

Temperature Range

-25°C to +70°C (-13°F to +158°F)

Weight

100 Grams
