DATAEAGLE 3715A Compact Kit - Wireless PROFIBUS

$3,650.00

Leave a review

SKU: GC-SCH-DE-CPT-3715A-KIT

MPN: GC-SCH-DE-CPT-3715A-KIT

Manufacturer: Schildknecht AG

Delivery: Ships within 7-14 business days
Qualifies for Free shipping to the US
Antenna not included.
Please contact sales for help selecting the correct antenna for your application.
Call for information or to order.
Phone: (800) 975-4743 or (630) 245-1445
Email: sales@gridconnect.com

Product Information

Product Description

The 3715A DATAEAGLE Compact Kit is an easy to use wireless network for PROFIBUS DP data transfers. The kit includes 2 pre-paired radios (1 master, 1 slave) for plug & play implementation. An antenna is not included.  Contact sales to select the correct antenna for your application.

The system operates on a highly reliable 2.4 GHz Bluetooth, 100m W (EIRP) frequency and is capable of data transmission up to 1.5 Mbit/s.

This device supports 1 radio slave and up to 4 PROFIBUS DP slaves. All devices with a PROFIBUS DP interface can be tied in with radio links, allowing the device to be implemented in existing networks and providing the convenience of wireless transfers.

An IP20 rated case and DIN rail mounting allow the devices to be placed in a variety of locations. The patent filter technology makes it possible for data transmissions up to 100 meters indoors and 300 meters in open areas.


Compare DATAEAGLE 3000 Series.

Common Applications Include:
  • Storage systems
  • Transport vehicles
  • Lifts/elevators
  • Machine construction
  • Automotive industry
  • Cranes/crane systems
  • Water/sewage and raw materials management
  • Replacement of trailing cable/cable chains
  • Replacement of optical coupler
  • Replacement of conductor lines
  • Replacement of slip rings



Features

  • 1.5 Mbit/s PROFIBUS DP transmission rate
  • Max. number of radio slaves: 1
  • Max. number of DP slaves: 4
  • IP20 rated case
  • 24V DC power supply
  • DIN rail mounting
  • 2.4 GHz Bluetooth, 100m W (EIRP)
  • Transmission range up to 100 meters (indoors)
  • Transmission range up to 300 meters (outdoors)

Documents and Drivers

Documentation

DataEagle 3715A Compact User Manual

DataEagle 3000 Series Datasheet

DataEagle 3000 Compact Series Quick Reference Guide

Specifications

Antennas

SMA Connection - 50 Ohm

Cable Length

5 m

Certifications

CE, FCC

Connector(s)

Terminal clamps and 9 pol. SUB D

Dimensions

114.5 mm x 22.5 mm x 99 mm

Enclosure

IP20 rated case

Frequency Band

2.4 GHz Bluetooth

Included in Box

  • 1 DataEagle Compact 3715A Master
  • 1 DataEagle Compact 3715A Slave
  • 2 Omnidirectional Antenna
  • 3 dB with magnetic base and connecting cable (5m)

Interface(s)

PROFIBUS

Mounting

DIN rail

MPN

11160, 11161

Power Consumption

100 mA

Power Supply

24 V DC

Product Weight

130 g

Range

  • Indoor: 100m
  • Outdoor: 300m

Temperature Range

-20ºC to 60ºC (-4ºF to 140ºF)

Transmission Speed

1.5 MBit/s

Transmit Power

100 mW (EIRP)
