Home / sensorProbe4 - 4 Port Sensor Monitoring Device (SP4N)

This product is discontinued and no longer available.

Suggested replacement: SPX4 - 4-Port sensorProbeX+ Standard Unit

sensorProbe4 - 4 Port Sensor Monitoring Device (SP4N): SP4N

Leave a review

SKU: GC-AK-SP4N

MPN: SP4N

Manufacturer: AKCP

Type

We've Got You Covered

delivery truck

1 year comprehensive warranty support for all products

hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

Authorized North America Distributor Stamp

The SensorProbe4 (SP4N) is an intelligent, high-speed monitoring device with 4 auto-sensing ports. The proprietary Linux like OS includes TCP/IP stack, remote Ethernet/web access, Email, and SMS messaging.

Setup is simple; assign the IP address and connect to the web server. Then connect any combination of AKCP intelligent sensors to the auto-sensing ports.

Sensors include integrated data collection and graphing to identify trends in temperature, humidity and airflow. Records of events will include a timestamp of when the event happened and the action taken.

Order Summary

SKU

Option Type

Manufacturer Part # (MPN)
GC-AK-SP4N SP4N SP4N
GC-AK-SP4N-POE SP4N with PoE SP4N-POE

Features

  • 4 auto-sense ports for connecting any AKCP intelligent sensors
  • Full Email and SMNP traps for notification features
  • Fully embedded TCP/IP and web-server
  • New improved web-based interface for easy configuration and monitoring
  • Login for User and Administrator for better security
  • Battery backed time of day clock for an accurate system date and time
  • No external hardware or software dependencies
  • Firmware update over the internet
  • Customized color configuration for displaying alerts
  • Network Management System integration
  • 1U rack mounting included

Documents and Drivers

Documentation

sensorProbe4 (SP4N) Datasheet

Specifications

Dimensions

44 (W) x 44 (H) low profile design

Humidity

Min. 20% - Max. 80% (Non-Condensing)

Indicators LED

Status for Power, Sensor online & threshold, Network

Input/Output

Inputs:

  • 4x Sensor Ports for connecting AKCP sensors*
  • 1x 10/100 Mbps Ethernet Port


Outputs:

  • Configurable output signals (0VDC/5VDC) on any of the 4 RJ-45 sensor ports

Mounting

  • 1U Rack Mount Standard
  • Rack mount brackets included

MPN

SP4N

MTBF

1,400,000 Hours based on field experience with sensorProbe units

Power

Input Voltage and Current ratings : 100V~240V – 0.22A

Power Consumption

Typical : 1.12Watt, 0.13A

Power Supply

5.5 VDC, 3 Amp

Temperature Range

-35°C to 80°C (-31°F to 176°F)
