This product is discontinued and no longer available.
Wireless Dual Temperature & Humidity Sensor
Wireless Dual Temperature & Humidity Sensor
Product Images
Product Information
Product Description
Use this wireless dual sensor for temperature and humidity to ensure environmental conditions are within required parameters by logging and graphing data over time. Receive real-time alerts when user defined sensor thresholds are exceeded.
Use the sensor as a data logger with data buffered and synchronized to the required gateway when in range. Pair sensor with any AKCP Wireless Tunnel™ gateway.
IP66 rated enclosure provides weatherproofing for use in outdoor environments. Mounting with DIN rail, wall hang or cable-tie / pipe clamp.
Order Summary
SKU |
Cable Length |
Manufacturer Part # (MPN) |
|---|---|---|
| GC-AK-WTS-TH (DISCONTINUED) | No Cable | WTS-TH-US |
| GC-AK-WTS-TH-5 (DISCONTINUED) | 5ft | WTS-TH-5-US |
Features
- 4x AA Battery powered, with 10 year life*
- 4x AA Batteries with 10 year guaranteed battery life*
- 5VDC or 12VDC powered
- IP66 rated waterproof enclosure
- LED indicators for power, status and RSSI
- Optional DIN rail or pipe mounting accessories
- Optional cable up to 15ft for sensor placement
- *10 years at 25°C broadcasting every 15 minutes. Batteries not included.
Documents and Drivers
Documentation
Wireless Dual Temperature & Humidity Sensor Datasheet
Specifications
Accuracy
25°C ±2%RH
Certifications
FCC Part15C, CE EN300220-2
Dimensions
76 x 77 x 120mm (2.99in x 3.03in x 4.72in)
Humidity
Min. 20% – Max. 80% (Non-Condensing)
Interface(s)
Micro-USB port for powering, adding and upgrading to the Gateway base unit
Measurement Accuracy
- Typical: ±0.3 from -40ºC to +75ºC (±0.4 from -40ºF to +167ºF)
- Maximum: ±0.4 at -40ºC and ±0.4 at +75ºC (±0.7 at -40ºF and ±0.7 at +167ºF)
Measurement Range
- -40°C to +75°C (-40°F to +167°F)
- 0 to 100% Relative humidity
Measurement Resolution
- 0.1°C increments
- 0.2°F increments
- 1%RH increments, 0.01%RH sensor reading
Mounting
Wall hanging, DIN rail, Pipe Clamp
MPN
WTS-TH
Power Consumption
Average 12 mWatt, 10uA in Idle, up to 10 years battery life
Power Source
4xAA batteries or via micro-USB port
Radio
LoRa (R) Radio Regional plans: US915: 903~915Mhz, Max TX Power +17dBm
Sensor(s)
Gateway sensor count 5 (3 + 2)
Temperature Range
-35°C to 80°C (-31°F to +176°F)
