Contactless Current Meter Sensor

$129.00

Leave a review

SKU: GC-AK-CCM

MPN: CCM

Manufacturer: AKCP Co Ltd.

Delivery: Ships within 7-14 business days
Qualifies for Free shipping to the continental US
This sensor REQUIRES an AKCP sensorProbe controller.

We Have You Covered

Price Match delivery truck hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

The AKCP Contactless Current Meter doesn't require having to access an individual wire which is what most current transformers require. This non-invasive meter sensor allows you to monitor current (and power if you have a reference voltage) in 2 core or 3 core cables.

This meter sensor has an unique current measurement technology making measuring individual IT rack current and power simpler, and at a lower cost. You can even check how close you are to tripping breakers, and in calculating live PUE numbers.

Product REQUIRES an AKCP sensorProbe controller.


Features


  • No downtime for installation
  • No electrician required
  • Input for PUE calculations
  • Rack level current monitoring
  • Accurate +/- 5%
  • Input for AKCP sensorCFD (sold separately)

Documents and Drivers

Documentation

Contactless Current Meter Sensor Datasheet

Specifications

Accuracy

  • +/- 5% when factory calibrated on cable of same type
  • +/- 10% on non-factory calibrated cable

Cable Length

50ft using standard CAT5/6 UTP cable

Dimensions

49mm x 45mm x 51mm WxHxD (1.93in x 1.77in x 2in)

Communications Cable

RJ-45 jack to sensor using UTP CAT5e cable

Humidity

Min. 20% – Max. 80% (Non-Condensing)

Indicators LED

  • LED indication for power
  • LED array for calibration

Input(s)

Magnetic field sensing of current in multicore cable

Mounting

Cable Mounted

Power

Powered by the controller unit. No additional power needed

Power Consumption

Typical 7.25mWatt, 1.45mA

Temperature Range

-35°C to +80°C (-31°F to +176°F)
