This product is discontinued and no longer available.
sensorProbe2 POE- Intelligent Sensor Monitor
sensorProbe2 POE- Intelligent Sensor Monitor
The SensorProbe2 allows for monitoring of two intelligent sensors from anywhere in the world. Set up threshold conditions through an easy webpage interface, and be alerted via Email or SMS Text message (via a 3rd party email-to-SMS gateway), or via SNMP traps into a SNMP monitoring system, and stop worrying! Pull up a web page and check the status at anytime.
The SensorProbe2 is an intelligent two-port sensor device for monitoring environmental variations (temperature, humidity, airflow etc), power, physical threats and security. The SP2 has an embedded host processor with a proprietary Linux like Operating System, including TCP/IP stack, Web server, email, SMS and full SNMP functionality.
The SensorProbe2 comes with a high speed CPU, fast network connection and web interface including subnet mask and remote syslog interface. It also has a battery backed time of day clock! The SensorProbe2 also has advance events filtering options. Now you can plug in our motion detector to the SensorProbe2!
SensorProbe2 also works with the relative humidity and temperature multi sensor module comprising a calibrated digital output. By having both temperature & humidity sensors in a single sensor, the SensorProbe2 can have up to a maximum of 2 temperature & 2 humidity sensors. This extends the capability of the SensorProbe2 to maximum of 4 sensing parameters!
The SensorProbe2 works with every intelligent sensor we sell. You can connect any of our plug-and-play sensors, in any combination to monitor temperature, humidity, water leakage, airflow, security, detect AC Power Line Voltage, Measure DC Voltage, control relays, and more. Our sensors include an integrated data collection and graphing package to spot trends in the airflow, temperature, humidity, etc.
Dry contacts and drivers are available for monitoring UPS status, security systems, and air conditioning status. With the optional Dry Contact Software, you can add up to 10 Dry Contacts (5 per port) to the SP2!
Every sensor comes with our unique autosense feature. Whenever a new type of sensor is plugged in, the autosense will recognize it and re configure the SP2 to begin monitoring it. In the event of an alarm or temperature / humidity threshold being exceeded, it has ability to send alert notification using Email, SMS and SNMP Traps.
The SensorProbe2’s advanced encrypted micro code updating program can update the SensorProbe2 firmware over the internet.
A web based interface with a user and administrator login feature helps users to prevent unauthorized access to the device and a powerful embedded system logging features is available. Setup is easy with the embedded web server. There is a simple graphing utility integrated into the SP2 which can monitor every temperature, humidity and other sensors and display a graphical report.
The SP2 is fully SNMP compliant and configurable. Following initial configuration by the RJ45 port to set basic parameters such as IP address, Subnet Mask, Default gateway, SNMP community strings, trusted IP addresses and trap destinations, the unit is fully configurable from any SNMP terminal or Network Management product.
The SensorProbe2 is supplied with a MIB to allow its interface to SNMP based Network Management systems such as HP OpenView, IBM Tivoli, CA Unicenter, TNG and others.
Manufacturer Part # (MPN)
|GC-AK-SP2-POE||None||Power Over Ethernet (PoE)||SP2POE (DISCONTINUED)|
|GC-AK-SP2-POE-T01||Temperature Sensor 1 ft.||Power Over Ethernet (PoE)||SP2POET01 (DISCONTINUED)|
|GC-AK-SP2-POE-TH01||Temperature/Humidity Sensor 1 ft.||Power Over Ethernet (PoE)||SP2POEdTH01 (DISCONTINUED)|
|GC-AK-SP2||None||US/North America||SP2 (DISCONTINUED)|
|GC-AK-SP2DTH01||Temperature/Humidity Sensor 1 ft.||US/North America||SP2 (DISCONTINUED)|
|GC-AK-SP2DTH01-220||Temperature/Humidity Sensor 1 ft.||European||SP2 (DISCONTINUED)|
|GC-AK-SP2T01||Temperature Sensor 1 ft.||US/North America||SP2 (DISCONTINUED)|
|GC-AK-SP2T01-220||Temperature Sensor 1 ft.||European||SP2 (DISCONTINUED)|
- Built-in web server for easy set-up, configuration and monitoring
- Supports all major communications protocols
- Supports 2 of our intelligent autosense plug-and-play sensors simultaneously
- Fully SNMP compliant
- Includes SNMP MIB
- Includes SNMP utilities for setting and getting parameters. Example programs to read and control the sensorProbe
- Supports SNMP polling which allows sensor values to be collected and graphed with host applications
- Sends trap notifications to two destinations
- Sends email notifications to two email addresses
- Email and traps include the sensor description, current sensor value
- Thresholds can be set for all sensors
- Data Collection of 8,640 data points per port (Ex: Sensor polling every 15 Minutes = Roughly 3 Months worth of Data)
Documents and Drivers
|SP2 Datasheet||View (PDF)|
|Firmware Information & Downloads
This link goes to AKCP's Support Center where you can login or setup an account.
Network: 10 Base-T Ethernet RJ-45
4.5" x 2.5" x 1.25"
Power, Network Connectivity, Threshold Status
- 2 - RJ-45 ports for connecting our intelligent sensors
- Configurable analog inputs on either sensor port (0-5VDC)
- Configurable output signals (0VDC/5VDC) on either RJ-45 sensor port
Rackmount, surface mount or desktop
PRODUCT POWER SUPPLY
5 VDC, 3 Amp
- Operating: -35°C to +55°C
- Humidity: 20% to 80% (non-condensing)
