CAN USB PRO FD Adapter - 2 Channels: CAN & LIN

$708.00

SKU: GC-CAN-USB-PRO-FD

MPN: IPEH-004061

Manufacturer: Peak System Technik

Stock Status: In stock

Delivery: Ships same or next business day
Qualifies for Free shipping to the continental US

We Have You Covered

Price Match delivery truck hand receiving items

30 day money back guarantee

*some exceptions apply

Product Information

Product Description

Advanced PC Interface for CAN FD and LIN Networks.

The PCAN-USB Pro FD Adapter, a professional-grade CAN USB adapter, enables simultaneous access to two independent CAN FD and two LIN channels. Ideal for lab and field applications, it integrates seamlessly with modern Windows systems and includes diagnostics tools for real-time monitoring.

Designed to meet rigorous automotive and industrial communication requirements, the adapter supports both ISO and non-ISO CAN FD standards. Each channel is galvanically isolated, enhancing signal integrity and protection in complex environments.

Engineers benefit from support for bitrates up to 12 Mbps, real-time timestamping, and programmable termination. The robust aluminum housing ensures durability during portable and in-vehicle use.

Included software, PCAN-View and PLIN-View, and software interfaces, PCAN-Basic and PLIN-API, empower developers to test, simulate, and validate bus communication efficiently.

Fully compatible with PEAK-System’s API ecosystem, this adapter is trusted by industry professionals working with CANopen, J1939, LIN 2.2, and custom protocols.

Requires use of PCAN-USB driver version 4.



Compare top CAN USB Adapters

Features

Overall Adapter Features:

  • Transmit and receive CAN FD and LIN messages via 2 D-Sub connectors (both support CAN FD and LIN pin assignments)

  • USB 2.0 high-speed interface (compatible with USB 1.1 and USB 3.0)

  • 1 μs timestamp resolution for precise message logging

  • 5V output available at the D-Sub connector via solder jumper (e.g., for powering external converters)

  • USB-powered—no external supply required

  • Extended operating temperature: −40 °C to +85 °C (−40 °F to +185 °F)

  • Rugged aluminum housing suitable for field and lab use

CAN Operation Properties:

  • FPGA-based CAN FD controller implementation

  • Compliant with CAN 2.0 A/B and ISO/non-ISO CAN FD 1.0

  • CAN FD data field bitrates: 40 kbit/s to 12 Mbit/s (up to 64 bytes)

  • Classic CAN bitrates: 40 kbit/s to 1 Mbit/s

  • NXP TJA1044GT CAN transceivers

  • Independent galvanic isolation (up to 500 V) for each CAN FD channel

  • Optional termination configurable via solder jumper

  • Bus load monitoring, including error and overload frames

  • Error frame generation for stress and resilience testing

LIN Operation Properties:

  • Supports LIN bitrates from 1 kbit/s to 20 kbit/s

  • TJA1021/20 LIN transceiver

  • LIN channel opto-decoupled from CAN and USB interfaces (shared ground)

  • Operable as both LIN master or slave with 1 ms master task resolution

  • Auto-detection of bit rate, frame length, and checksum type

  • Integrated scheduler with support for unconditional, event, and sporadic frames

  • Up to 8 configurable schedule tables with a total of 256 frame slots

Documents and Drivers

Documentation

PCAN-USB-PRO FD User Manual

Downloads

PEAK-System PCAN DOWNLOAD SUPPORT

Specifications

Baud Rate

  • CAN: max. 1 MBit/s
  • 1 kbit/s – 20 kbit/s

CAN FD

567

Certifications

CE, RoHS

Connector(s)

USB

Controller(s)

CAN/LIN: NXP / Philips SJA1000

Dimensions

120 x 71 x 24 mm

EMC Directive

  • EN 55024:2003-10
  • EN 55022:2007-04
  • EC directive 2004/108/EG

Enclosure

IP54, Metal Enclosure

Humidity

15% to 90% (non-condensing)

Interface(s)

  • PC: USB plug type A, USB 1.1, compatible to USB 2.0 5V
  • CAN/LIN: ISO 11898-2, complies with CiA-recommendation DS 102

IO and IRQ

Automatically assigned via "plug n play"

Isolation

500 VDC

MPN

IPEH-004061

Pinout

C.I.A. DS-102 (CAN_H = 7, CAN_L = 2, CAN_GND = 3)

Power Consumption

USB 5V max. 200 mA

Product Weight

220 g

Software

  • Driver: Windows® 7, Vista, XP; Linux
  • Tools: PCAN-View for Windows®

Specifications

CAN/LIN: 2.0A (Standard format) and 2.0B (extended format) , LIN specification 2.1

Temperature Range

Storage: -40°C to +100°C (-40°F to +212°F)

Operating: -40°C to +85°C (-40°F to +185°F)

Transceiver

CAN/LIN: MAX 3057ASA / AMIS-30600
